Kombi I Combination Valves
Kombi I combination valves are a one piece combination valve designed to control the compressed air supply in and out of the blast pot. A single piston and pinch ram assembly is utilized to open and close the valve’s inlet and outlet section simultaneously. Use up to 1-5/8″ blow down blast hose. Features 1-1/4″ NPT threads. For repair kit see part # 30-902. Finally, use this remote control valve to replace your old Schmidt style combo valves.
Features:
- Aluminum casing
- one-piece construction for easy installation
- single piston design
- 1-1/4″ NPT threads (32mm)
- Repair/Rebuild kit 30-902
OEM Equivalent:
- Blast-it-all 16-877
- Schmidt 2223-000
- IDS 888-2223-000PB
Blue Dog Blasting SKU #
- 30-901
Click here for Product Operating Manual
Kombi II Combination Valves
Kombi 2 combination valves, much like the Kombi 1, are a one piece combination valve designed to control the compressed air supply in and out of the blast pot. Made out of cast iron instead of aluminum, it is stronger than the Kombi 1. A single piston and pinch ram assembly is utilized to open and close the valve’s inlet and outlet section simultaneously. Use up to 1-5/8? blow down blast hose. Also features 1-1/4? NPT inlet threads. The best part is, service can easily be made without removing the valve. Replaces Schmidt style combo valves. Installation is plug & play. For repair kit, see part # 30-902
Features:
- Durable cast iron air inlet flow chamber
- Integrated exhaust hose crimp chamber with clear acrylic inspection window
- Upgraded easy maintenance pistons
- Full flow 1-1/4? NPT inlet
- Powder coat external finish
- Anodized internally
- Repair/Rebuild kit 30-902
Advantages:
- Rebuild while still attached to blast pot pipe string
- Has inspection window to monitor blow down hose wear
- Combo valve style means two valves in one. Inlet and outlet valve combined.
OEM Equivalent:
- Blast-it-all 16-877
- Schmidt 2223-000
Blue Dog Blasting SKU#
- 30-903
Click here for a Product Operating Manual.
Kombi III Combination Valves
New and Improved! The Kombi 3 combination valve is high flow rate combo type valve. The inlet and exhaust sides of this combo valve work together with our AirStop remote deadman to simultaneously control the blast pot supply air and exhaust. The Kombi III features updated materials and a simplified design over the original Kombi I. The 1-1/2″ NPT thread flow ports are
Replaces Schmidt style combo valves. Installation is plug & play. For repair kit, see part # 30-902
Features:
- 44% larger flow area than Kombi I and Kombi II.
- Simplified, integrated design
- Redesigned upper rod guide
- Clear acrylic top cover allows inspection fo the exhaust hose
- Full flow 1-1/2? NPT inlet
- Powder coat external finish
- Anodized internally
- Repair/Rebuild kit 30-902
Advantages:
- Rebuild while still attached to blast pot pipe string
- Has inspection window to monitor blow down hose wear
- Combo valve style means two valves in one. Inlet and outlet valve combined.
- Bigger air inlet. 1-1/2″ NPT.
OEM Equivalent:
- Blast-it-all 16-877
- Schmidt 2223-000
Blue Dog Blasting SKU#
- 30-904
